71 -Maintenance Procedures
b) CAS2 installed on the belt drive side of the engine with engine harness revision
AD.1 or higher
If the CAS2 sensor is installed as shown in Fig. 71 - 80 and the engine harness is E4A(B)-95-000-
000 revision AD.1 or higher, do the instructions in this paragraph.
Fig. 71 - 80 CAS2 installed on the belt drive side of the engine
CAS2 position on the belt drive side
