17 Appendix
540
Appendix
17
îš„High Capacity Paper Tray Specifications
Dimensions/weight Width 824 x Depth 650 x Height 1,010 mm, 81 kg
Width 829 x Depth 650 x Height 1,058 mm, 81 kg
(when the extension flap is extended)
Space requirements
(when connected to the
main unit)
Width 1,805 x Depth 677 mm
(main unit + C Finisher, when the bypass tray is extended
completely).
Paper size/type Maximum: A4 , 8.5 x 11" Minimum: B5 , 56-216 g/m
2
Paper feed capacity 2,000 sheets x 1 tray
Important• 80 g/m
2
paper
Dimensions/weight Width 389 x Depth 610 x Height 380 mm, 29 kg
Space requirements
(when connected to the
main unit)
Width 976 x Depth 649 mm
(main unit (when the bypass tray is extended completely) + high
capacity paper tray)
To Next Page
