Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

9.10.4 Replacing an FBU 325
10 Main memory
329
10.1 Safety notes 329
10.2 Basic information 330
10.2.1 Slots and features 330
10.2.2 General memory population rules 332
10.2.3 DDR4 only - memory population rules 333
10.2.4 DDR4 and Optane PMem - memory population rules 334
10.3 Installing memory modules 336
10.4 Removing memory modules 340
10.5 Replacing memory modules 341
10.6 Handling memory dummy modules 343
11 Processor (CPU) 345
11.1 Safety notes 345
11.2 Basic information 346
11.3 Upgrading to 2 CPUs configuration 348
11.4 Replacing a CPU or heat sink 359
12 Liquid cooling (LC) 367
12.1 Safety notes 367
12.2 Basic information 368
12.3 Replacing the CPU for LC device 369
Content
Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
