Fujitsu PRIMERGY RX2540 M6

Installing a memory module
Figure 214: Opening the securing clips
▶
Press the securing clips on both sides of the memory slot concerned
outward.
▶
If applicable, remove the dummy module.
A
Figure 215: Installing a memory module
▶
Align the notch (A) on the bottom of the module with the crossbar in the slot.
▶
Press down on the memory module (1) until the securing clips snap into the
cutouts at each end of the module (2).
Main memory
338 Upgrade and Maintenance Manual RX2540 M6
