Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Preliminary steps
▶
"Locating the defective server" on page 49
.
▶
"Note on network settings recovery" on page 265.
▶
"Suspending BitLocker functionality" on page 87.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
Disconnect all external cables.
▶
If applicable, remove the OCP modules, see "Removing an OCP module"
on page 252.
▶
Remove all PSUs, see "Removing a hot-plug PSU" on page 127.
▶
"Getting access to the component" on page 56.
▶
For a system with air cooling, proceed as follows:
▶
"Removing the air duct" on page 78.
▶
Remove all memory modules, see "Removing a memory module" on
page 341.
Before removing the memory modules, take a note on the
installation slot number for each memory module. Ensure that you
reinstall the memory modules in the slot they were located before
the replacement.
CAUTION
In case of Optane PMem modules are not reinstalled in the right
slots, data can be lost!
▶
If applicable, remove all dummy memory modules, see "Removing a
memory module" on page 341
.
System board and components
RX2540 M6 Upgrade and Maintenance Manual 523

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
