Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

▶
For a system with liquid cooling, proceed as follows:
▶
Remove the LC kit, see "Removing the LC kit" on page 370.
▶
Remove all memory modules, see "Removing a memory module" on
page 341.
Before removing the memory modules, take a note on the
installation slot number for each memory module. Ensure that you
reinstall the memory modules in the slot they were located before
the replacement.
CAUTION
In case of Optane PMem modules are not reinstalled in the right
slots, data can be lost!
▶
Remove all riser modules, see "Removing a riser module" on page
70
.
▶
"Removing the fan cage" on page 74.
▶
"Removing the cross bar" on page 80.
▶
If applicable, remove all expansion cards, see "Removing the expansion
card" on page 263.
▶
Remove the iRMC microSD card, see "Removing the iRMC microSD card"
on page 493.
▶
If applicable, remove all M.2 SSDs, see "Removing the M.2 SSD" on
page 503.
▶
If applicable, remove the Dual microSD 64GB Enterprise, see "Removing
the Dual microSD 64GB Enterprise" on page 510.
Removing the defective system board
▶
Disconnect all cables from the system board.
System board and components
524 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
