Fujitsu PRIMERGY RX300 S8

132 Upgrade and Maintenance Manual RX300 S8
Hard disk drives / solid state drives
7.3.1.3 HDD / SSD mounting order for 8x 2.5-inch HDD / SSD
configurations
Figure 39: 2.5-inch HDD / SSD mounting order configuration 4
Figure 40: 2.5-inch HDD / SSD mounting order configuration 6
2.5-inch HDDs / SSDs
HDD RAID Manager # Channel
1 [0] 1
2 [1] 1
3 [2] 1
4 [3] 1
Table 6: HDD naming scheme
