RX300 S8
Upgrade and Maintenance Manual 245
Main memory
10.1.1 Memory sequence
10.1.1.1 Population rules
– Populate memory slot 1 / channel A (DIMM 1A) first.
– In case of dual processor configurations, populate memory slot
1 / channel E (DIMM 1E) second.
– Within all channels, memory slot 1 must be populated prior to slot 2.
Slot 2 must be populated prior to slot 3 (for all CPUs).
– If memory modules with different ranks are used, always populate the higher
number rank DIMM first (starting from slot 1).
– If memory modules with different capacities are used:
– Populate modules with higher capacities first.
– Within a channel, populate modules in descending order of capacity.
– If memory modules with different speeds are used, the lowest clock rate
applies for all DIMMs.
Regardless of the mode, all DIMMs will run at the highest common
frequency that is allowed by the SPD Data of the DIMMs and the maximum
speed of the selected configuration.
– Mixing UDIMMs, RDIMMs or LRDIMMs is not allowed.
– Mixing ECC and non-ECC DIMMs is not allowed.
Type
Ranking
1
1
SR: Single-Rank, DR: Dual-Rank, QR: Quad-Rank
Error
Correction
SR DR QR
DDR3-1600
PC3-12800
DDR3-1866
PC3-14900
DDR3-1333
PC3-10600
RDIMMs
(Registered DIMMs)
xxx
ECC or non-
ECC
UDIMMs
(Unbuffered DIMMs)
xx
LRDIMMs
(Load-Reduced
DIMMs)
x
