244 Upgrade and Maintenance Manual
RX300 S8
Main memory
10.1 Basic information
Figure 131: Memory overview
– The system board is equipped with 24 memory slots
(12 connectors per CPU).
– In mono processor configurations only 12 memory slots are usable.
– The system has to be equipped with at least one memory module per
processor.
– Supported capacities: 2 GB, 4 GB, 8 GB, 16 GB, 32 GB or 64 GB
– Maximum amount of RAM: 1536 GB (768 GB per CPU)
– Supported memory modules:
CPU 1
CPU 2
DIMM 1H
DIMM 2H
DIMM 3H
DIMM 1G
DIMM 2G
DIMM 3G
DIMM 3E
DIMM 2E
DIMM 1E
DIMM 3F
DIMM 2F
DIMM 1F
DIMM 1B
DIMM 2B
DIMM 3B
DIMM 1A
DIMM 2A
DIMM 3A
DIMM 3C
DIMM 2C
DIMM 1C
DIMM 3D
DIMM 2D
DIMM 1D
