198 Upgrade and Maintenance Manual
RX300 S8
Expansion cards and backup units
Ê "Shutting down the server" on page 54
Ê "Disconnecting power cords" on page 54
Ê "Getting access to the component" on page 57
Ê "Removing the slot bracket" on page 182
Ê Remove the Modular LAN controller from its protective packaging.
I For further instructions regarding controller settings, please refer to
the accompanying documentation.
Ê "Installing a slot bracket to the Network adapter D2755" on page 178
9.5.2.2 Connecting the NCSI sideband cable to the Modular LAN
controller
I If the Modular LAN controller is to be used for dedicated network
connections only, please skip this section.
Figure 94: NCSI sideband cable
