500 Upgrade and Maintenance Manual
RX300 S8
Appendix
17.5 Minimum startup configuration
If the server does not start up or other problems occur, it may be necessary to
take the system down to its most basic configuration in order to isolate the
defective component.
The minimum startup configuration consists of the following components and
cables:
Setting Status Description
1JP1
Password
Skip/Recovery
BIOS
Default: Password delete and
Recovery BIOS options disabled
PWD SKIP: Password delete
enabled
This jumper setting will
permanently delete the current
BIOS password and apply default
BIOS settings.
RCVR: Recovery BIOS enabled
2
BIOS-
WP
Flash Write
Protect
Default
Flash Write Protect enabled
3JP8
Flash Security
Disable
Default
Flash security disabled
Field Replaceable Unit
(FRU)
