Front panel and external connectors
13.3.1.2 Removing the front panel module
Ê "Removing the front panel module" on page 363
Ê If applicable remove the front VGA connector see section "Removing the
front VGA connector" on page 373.
13.3.1.3 Preparing the front panel module
Figure 241: Breaking out the front LAN cover plate
Ê Break out the LAN cover plate on the front panel cover.
I Please note that once removed, the front LAN cover plate cannot be
refitted.
