188 Upgrade and Maintenance Manual
RX300 S8
Expansion cards and backup units
9.3.3 Replacing expansion cards
Note on network settings recovery
I When replacing network controllers or the system board, network
configuration settings in the operating system will be lost and replaced
by default values. This applies to all static IP address and LAN teaming
configurations.
Ensure to note down your current network settings before replacing a
controller or the system board.
9.3.3.1 Preliminary steps
Ê If applicable, "Note on network settings recovery" on page 188.
Ê "Disabling BitLocker functionality" on page 73
Ê "Disabling SVOM boot watchdog functionality" on page 74
Ê "Locating the defective server" on page 51
Ê "Shutting down the server" on page 54
Ê "Disconnecting power cords" on page 54
Ê Remove all external cables from the expansion card to be replaced.
Ê "Getting access to the component" on page 57
Ê Locate the defective expansion card using the onboard Local Diagnostic
LEDs as described in section "Onboard indicators and controls" on
page 489.
9.3.3.2 Removing an expansion card
Ê If applicable, "Removing an SFP+ transceiver module" on page 238.
Ê "Removing expansion cards" on page 185
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
