RX300 S8
Upgrade and Maintenance Manual 153
Hard disk drives / solid state drives
I For a complete cabling overview, please refer to section "List of used
cables" on page 465.
7.4.2.6 Concluding steps
Ê "Installing the fan box" on page 164
Ê "Installing the front cover" on page 446
Ê "Reassembling" on page 63
Ê "Installing 2.5-inch HDD / SSD modules" on page 135
Ê "Connecting the server to the power source" on page 69
Ê "Switching on the server" on page 71
Ê "Enabling BitLocker functionality" on page 95
7.4.3 Replacing the 12x 2.5-inch HDD SAS backplane
7.4.3.1 Preliminary steps
I The 2.5-inch HDD SAS backplane is mounted on the drive cages. It is
not necessary to remove the drive cage before replacing the SAS / SATA
backplane
Ê "Locating the defective server" on page 51
Ê "Disabling BitLocker functionality" on page 73
Ê "Shutting down the server" on page 54
Ê "Disconnecting power cords" on page 54
Ê Remove all HDD / SSD modules from the server as described in section
"Removing 2.5-inch HDD / SSD modules" on page 138.
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
