RX300 S8
Upgrade and Maintenance Manual 465
16 Cables
This chapter provides information on how to connect, disconnect and route
cables.
Safety notes
V CAUTION!
●
Always hold cables by their connectors when disconnecting them.
Never pull on the cable to disconnect cables.
●
Ensure that none of the cables are scraped, strained or otherwise
damaged while replacing system components.
●
Immediately replace cables with damaged shielding.
●
Always use shielded network cables.
16.1 List of used cables
No Name
Cable
number
Routing
Configuration
12345678
C1
LTG PWR
SB 150
T26139-
Y3758-V10
from power
backplane to
system board
oooooooo
C2
LTG SMB
PWR-BP
T26139-
Y4027-V2
from power
backplane to
system board
oooooooo
C3
LTG PWR
SAS-BP
3.5
T26139-
Y3939-V501
6x 3.5-inch SAS
BP to system
board
o
C4
LTG PWR
SAS-BP
T26139-
Y3939-V201
2.5-inch SAS
BP(s) to system
board
ooooooo
C5
LTG PWR
3ST 600
T26139-
Y3986-V303
SAS BP(s) to
DVD drive
ooooooo
Table 10: List of used cables
