RX300 S8
Upgrade and Maintenance Manual 375
Front panel and external connectors
Ê "Connecting the server to the power source" on page 69
Ê "Switching on the server" on page 71
Ê "Enabling BitLocker functionality" on page 95
13.2.3 Replacing the front VGA connector
13.2.3.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 73
Ê "Locating the defective server" on page 51
Ê "Shutting down the server" on page 54
Ê "Disconnecting power cords" on page 54
Ê "Getting access to the component" on page 57
Ê "Removing the fan box" on page 162
13.2.3.2 Removing the front panel module
Ê "Removing the front panel module" on page 369
13.2.3.3 Removing the front VGA connector
Ê "Removing the front VGA connector" on page 374.
13.2.3.4 Installing the new front VGA connector
Ê Install the new front VGA connector as described in section "Installing the
front VGA connector" on page 370.
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Socket screw driver (5 mm)
Wrench key for UNC #4-40 hexagon bolts
