RX300 S8
Upgrade and Maintenance Manual 299
Accessible drives
Figure 169: Accessible drive (tape/RDX) in HDD bay for 2.5-in HDD version
12.2 Installing a Local Service Display (LSD)
module
12.2.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 73
Ê "Shutting down the server" on page 54
Ê "Disconnecting power cords" on page 54
Ê "Getting access to the component" on page 57
Ê "Removing the fan box" on page 162
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: tool-less
