Fujitsu PRIMERGY RX300 S8

RX300 S8 Upgrade and Maintenance Manual 483
17 Appendix
17.1 Mechanical overview
17.1.1 Server front
Figure 337: Server front side
Pos. Component
1 LSD module
2 Front panel module
3 Optical disk drive
4
Space for hard disc drives and backup drives (depending on the
configuration)
