386 Upgrade and Maintenance Manual
RX300 S8
Front panel and external connectors
13.3.2 Removing the front LAN connector
13.3.2.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 73
Ê "Locating the defective server" on page 51
Ê "Shutting down the server" on page 54
Ê "Disconnecting power cords" on page 54
Ê "Getting access to the component" on page 57
Ê "Removing the fan box" on page 162
13.3.2.2 Removing the front LAN board
Figure 251: Disconnecting the front LAN board
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
