RX300 S8
Upgrade and Maintenance Manual 359
Accessible drives
12.16 Replacing the LTO drive in 2.5-inch version
12.16.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 73
Ê "Locating the defective server" on page 51
Ê "Removing backup and optical disk media" on page 76
Ê "Verifying and configuring the backup software solution" on page 77
Ê "Shutting down the server" on page 54
Ê "Disconnecting power cords" on page 54
Ê "Getting access to the component" on page 57
Ê "Removing the front cover" on page 443
Ê "Removing the fan box" on page 162
12.16.2 Removing the defective LTO drive
Ê "Removing the drive cage" on page 351
Ê "Removing an LTO drive out of the cage" on page 354
12.16.3 Installing the new LTO drive
Ê "Installing an LTO drive in the cage" on page 344
Ê "Installing the LTO cage" on page 347
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
