376 Upgrade and Maintenance Manual
RX300 S8
Front panel and external connectors
13.2.3.5 Re-installing the front panel module
Ê "Installing the front panel module" on page 365.
13.2.3.6 Concluding steps
Ê "Installing the fan box" on page 164
Ê "Reassembling" on page 63
Ê "Connecting the server to the power source" on page 69
Ê "Switching on the server" on page 71
Ê "Enabling BitLocker functionality" on page 95
13.3 Front LAN connector
13.3.1 Installing the front LAN connector
13.3.1.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 73
Ê "Locating the defective server" on page 51
Ê "Shutting down the server" on page 54
Ê "Disconnecting power cords" on page 54
Ê "Getting access to the component" on page 57
Ê "Removing the fan box" on page 162
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Slot screw driver
Phillips PH2 / (+) No. 2 screw driver
