RX300 S8
Upgrade and Maintenance Manual 253
Main memory
– In order to satisfy cooling requirements, populate memory channels on
alternating sides of the processor:
10.2 Installing memory modules
10.2.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 73
Ê "Disabling SVOM boot watchdog functionality" on page 74
Ê "Shutting down the server" on page 54
Ê "Disconnecting power cords" on page 54
Ê "Getting access to the component" on page 57
10.2.2 Installing a memory module
Ê Identify the correct memory slot see section "Memory sequence" on
page 245.
Order CPU 1 CPU 2
1 Channel A Channel E
2 Channel C Channel G
3 Channel B Channel F
4 Channel D Channel H
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
