Fujitsu PRIMERGY RX300 S8 Upgrade And Maintenance Manual

RX300 S8 Upgrade and Maintenance Manual 487
Appendix
17.3 Connectors and indicators
17.3.1 Connectors and indicators on the system board
17.3.1.1 Onboard connectors
Figure 340: Internal connectors of system board D2939
iRMC
external connectors
HDD LED
INDICATE
CSS
Intrusion
TPM
LAN
CTRL
Battery
VGA
USB
1/2
USB
3/4
Serial 1
Shared
LAN
LAN 2
Management
LAN
Slot 3 PCIe x8
Slot 4 PCIe x8 (mech. x16)
Slot 6 PCIe x16
Slot 5 PCIe x16
Slot 7 PCIe x8 (RAID)
Slot 2 PCIe x8
Slot 1 PCIe x8
CPU 2 DIMM 1E
CPU 2 DIMM 2E
CPU 2 DIMM 3F
CPU 2 DIMM 2F
CPU 2 DIMM 1F
CPU 2 DIMM 3E
CPU 2 DIMM 3H
CPU 2 DIMM 2H
CPU 2 DIMM 1G
CPU 2 DIMM 2G
CPU 2 DIMM 3G
CPU 2 DIMM 1H
PCH
CPU 1 DIMM 3B
CPU 1 DIMM 2B
CPU 1 DIMM 1A
CPU 1 DIMM 2A
CPU 1 DIMM 3A
CPU 1 DIMM 1B
CPU 1 DIMM 1C
CPU 1 DIMM 2C
CPU 1 DIMM 3D
CPU 1 DIMM 2D
CPU 1 DIMM 1D
CPU 1 DIMM 3C
CPU 2 CPU 1
1
JP1
JP8BIOS-WP
FAN 5
FAN 4
FAN 3
FAN 2
FAN 1
UFM
SATA 1SATA 2
SMB 4
USB
stick
SAS 1-4
USB
INT 2
USB
INT 1
SMB 1
Front PanelFront VGA
PWR
PWR
HDD/ODD
PSU Control
Front LAN M
NC-SI
SKU Key

Fujitsu PRIMERGY RX300 S8 Specifications

General

Memory	Up to 768 GB DDR3
Form Factor	2U rack server
Remote Management	iRMC S4 (Integrated Remote Management Controller)
Chipset	Intel C602
Processor	Intel Xeon E5-2600 v2 product family
Storage	Up to 16 x 2.5" or 8 x 3.5" drives
RAID	RAID 0, 1, 5, 6, 10, 50, 60
Network	4 x Gigabit Ethernet ports
Expansion Slots	6 x PCIe 3.0 slots
Operating System Support	Windows Server, Red Hat, SUSE, VMware
Memory Type	DDR3 RDIMM/LRDIMM
Power Supply	Hot-plug redundant power supply units
