488 Upgrade and Maintenance Manual
RX300 S8
Appendix
No. Print Description
1 PSU Control Power management connector
2 PWR ATX power supply connector
3 PWR HDD/ODD
4 Front LAN M Slot for front LAN connector board
5 Front VGA Front panel VGA connector
6 Frontpanel USB Front panel connector
7 SMB 1 LSD module
8 USB INT 1
USB 2.0 connectors for USB backup drives
9 USB INT 2
10 TPM Connector for Trusted Platform Module (TPM)
11 FAN1 - FAN5 FAN connectors
12 UFM Connector for USB Flash Module (UFM)
13 SATA 2 SATA 2 connector
14 SATA 1 SATA 1 connector
15 SMB 4
16 SAS 1-4 SATA MLC connector
