RX300 S8
Upgrade and Maintenance Manual 405
System board and components
Figure 267: Installing the UFM
Ê Connect the UFM to the system board, snapping in the UFM spacer.
14.3.1.3 Concluding steps
Ê "Reassembling" on page 63
Ê "Connecting the server to the power source" on page 69
Ê "Switching on the server" on page 71
Ê "Enabling SVOM boot watchdog functionality" on page 89
Ê "Enabling BitLocker functionality" on page 95
14.3.1.4 Software configuration
The UFM delivery set includes the "Recovery Tool CD" to setup the ESXi
configuration. Proceed as follows:
Ê Switch on the server.
1 UFM connector 2 Cut-out for UFM spacer
