234 Upgrade and Maintenance Manual
RX300 S8
Expansion cards and backup units
Ê "Switching on the server" on page 71
Ê If applicable, "Updating RAID controller firmware" on page 84.
Ê "Enabling SVOM boot watchdog functionality" on page 89
9.7 Handling SFP+ transceiver modules
For Fiber Channel over Ethernet (FCoE) configurations, the Ethernet server
adapter is equipped with one or two SFP+ (small form-factor pluggable)
transceiver modules.
9.7.1 Installing SFP+ transceiver modules
Preparing the SFP+ transceiver module
Figure 122: Removing the protective optical port plug
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tool: tool-less
