Fujitsu PRIMERGY RX300 S8 Upgrade And Maintenance Manual

298 Upgrade and Maintenance Manual RX300 S8
Accessible drives
12.1 Basic informations
Mounting order for accessible drives in the front panel cage
PRIMERGY RX300 S8 server offers one 5.25-inch accessible drive bays for
optical disk drives and backup drives:
Figure 166: Accessible drives in front panel cage
Mounting order for accessible drives in the HDD bays
PRIMERGY RX300 S8 server offers several possibilities to install tape drives:
Figure 167: Accessible drive in HDD bays for 3.5-inch HDD version
Figure 168: Accessible drive (LTO) in HDD bays for 2.5-in HDD version
No. Accessible drive Bay Max. no.
1 Local Service Display 3.5-inch bay 1
2 Optical disk drive 5.25 inch bay 1

Fujitsu PRIMERGY RX300 S8 Specifications

General

Memory	Up to 768 GB DDR3
Form Factor	2U rack server
Remote Management	iRMC S4 (Integrated Remote Management Controller)
Chipset	Intel C602
Processor	Intel Xeon E5-2600 v2 product family
Storage	Up to 16 x 2.5" or 8 x 3.5" drives
RAID	RAID 0, 1, 5, 6, 10, 50, 60
Network	4 x Gigabit Ethernet ports
Expansion Slots	6 x PCIe 3.0 slots
Operating System Support	Windows Server, Red Hat, SUSE, VMware
Memory Type	DDR3 RDIMM/LRDIMM
Power Supply	Hot-plug redundant power supply units
