310 Upgrade and Maintenance Manual
RX300 S8
Accessible drives
12.5.4 Installing an ODD
Figure 181: Installing the ODD
Ê Run the SATA and power cables through the ODD bay opening as shown.
Ê Connect the SATA cable to the ODD (1).
Ê Connect the power cable to the ODD (2)
Ê Insert the ODD into the bay and push in until it locks in place (3).
12.5.5 Concluding steps
Ê "Installing the fan box" on page 164
Ê "Reassembling" on page 63
Ê "Connecting the server to the power source" on page 69
Ê "Enabling BitLocker functionality" on page 95
