Cables
C6
LTG
COMMON
FP
T26139-
Y4015-V1
Front panel to
system board
ooooo o o o
C7
LTG SAS
2XMINI
110
T26139-
Y3963-V111
4x 2.5-inch SAS
BP to 12x2.5-
inch SAS BP
o
C8
LTG SAS
2XMINI
320
T26139-
Y3963-V101
SAS BP to SAS
controller
oo
C9
LTG SAS
2XMINI
470
T26139-
Y3963-V103
2.5-inch SAS BP
to SAS controller
oo
2
x
o
2
x
o
C10
LTG SAS
2XMIN
540
T26139-
Y3963-V116
2.5-inch SAS BP
to SAS on
system
board/SAS
controller
oooo o
C11
LTG SAS
2XMIN
650
T26139-
Y3963-V107
4x2.5-inch SAS
BP to SAS
controller
o
C12 LTG LVP T26139-
Y3718-V301
LSD to system
board (optional)
ooooo o
C13 LTG LAN
FP
T26139-
Y4025-V1
Front LAN to
system board
(optional)
ooooo o o o
C14 LTG INT
VGA 500
T26139-
Y3994-V101
Front VGA to
system board
(optional)
ooooo o o o
C15 LTG SATA
2XGER
750
T26139-
Y3928-V205
DVD to system
board (optional)
ooooo o
C16 LTG PWR
RDX 400
T26139-
Y2193-V501
tape/RDX to DVD
(optional)
o
No Name
Cable
number
Routing
Configuration
12345 6 7 8
Table 10: List of used cables
