Fujitsu PRIMERGY RX300 S8 Upgrade And Maintenance Manual

RX300 S8 Upgrade and Maintenance Manual 169
Expansion cards and backup units
Expansion card overview and installations sequence
Vendor/Type Bus Max# Slot 1 Slot2 Slot3 Slot4 Slot5 Slot6 Slot7
Misc
Nvidia
NVS300
x1
PCI2.0
11
PCIe USB
USB 3.0 x1
PCI1.0
11
SAS/RAID
D2616 RAID Ctrl SAS
6G 5/6 512 MB
x8
PCI2.0
11
D3116C RAID Ctrl
SAS 6G1GB
x8
PCI3.0
11
D2607 RAID Ctrl SAS
6G 0/1
x8
PCI2.0
11
9286CV RAID Ctrl
SAS 6G 8 ex 1GB LSI
V3
x8
PCI3.0
4 41532
Modular LAN
D2755 Dual Port
SFP+
x8
PCI2.0
11
D3045 Quad Port x4
PCI2.0
11
D2745 x4
PCI2.0
11
D3035 Dual Port x4
PCI2.0
11
D2735 x4
PCI2.0
11
PCIe-SSD (FusionIO)
365 GB MLC x8
PCI2.0
24132
785 GB MLC x8
PCI2.0
24132
1.2 TB MLC x8
PCI2.0
24132

Fujitsu PRIMERGY RX300 S8 Specifications

General

Memory	Up to 768 GB DDR3
Form Factor	2U rack server
Remote Management	iRMC S4 (Integrated Remote Management Controller)
Chipset	Intel C602
Processor	Intel Xeon E5-2600 v2 product family
Storage	Up to 16 x 2.5" or 8 x 3.5" drives
RAID	RAID 0, 1, 5, 6, 10, 50, 60
Network	4 x Gigabit Ethernet ports
Expansion Slots	6 x PCIe 3.0 slots
Operating System Support	Windows Server, Red Hat, SUSE, VMware
Memory Type	DDR3 RDIMM/LRDIMM
Power Supply	Hot-plug redundant power supply units
