RX300 S8
Upgrade and Maintenance Manual 295
Processors
Figure 165: Applying thermal paste
Ê Apply a dot of thermal paste to the center of the processor surface as shown.
I Two graduation marks on the syringe equal the correct amount of
thermal paste for one processor.
V CAUTION!
Do not mix different types of thermal paste.
