66 Upgrade and Maintenance Manual
RX300 S8
Basic hardware procedures
Additionally, a lifter is required in the following cases:
– The server weighs more than 50 kg.
– The server weighs more than 21 kg and is to be installed above the
height of 25 U.
When using a lifter, this installation procedure needs to be carried out by
maintenance personnel.
I Refer to the rack cabinet manuals for more detailed information on other
support systems.
Ê If required, install the rack mounting bracket and rack system into the rack
as described in the Rack Mounting Kit - RMK-F1/F2 DROP-IN Quick
Release Lever (QRL)" Mounting Instructions.
I The printed poster is contained in the rack mounting kit.
For configurations below 55 kg:
At least three people are needed to lift the server
into the rack cabinet.
For configurations above 55 kg:
At least four people are needed to lift the server
into the rack cabinet.
