SmartPAC 2 with WPC Integration 1126800
Installing SmartPAC 2 and WPC Chapter 2 page 87
Table 2 - 5. ProCamPAC to Cam Output Assembly TB301, Cams 1-8
Wire
8-cam: ProCamPAC TB401 (cams 1-8)
or 16-cam: ProCamPAC TB451 (cams 1-8)
(pin #)
1
st
Cam Output Board
TB301 (pin #)
CHAS (1)
White Relay Pwr (270)
A (3)*
Black GND (269)
B (2)*
Red +5 (268) +5 VDC (4)
Tan Ch 8 (267) Ch 8 (5)
Pink Ch 7 (266) Ch 7 (6)
Gray Ch 6 (265) Ch 6 (7)
Blue Ch 5 (264) Ch 5 (8)
Yellow Ch 4 (263) Ch 4 (9)
Orange Ch 3 (262) Ch 3 (10)
Purple Ch 2 (261) Ch 2 (11)
Brown Ch 1 (260) Ch 1 (12)
* Note that the pin numbers for A and B are out of order
Table 2 - 6. ProCamPAC to Cam Output Assembly TB301, Cams 9-16
Wire
16-cam: TB452
(9-16) (pin #)
2
nd
Cam Output Board
TB301 (pin #)
CHAS (1)
White Relay Pwr (281)
A (3)*
Black GND (280)
B (2)*
Red +5 (279) +5 VDC (4)
Tan Ch 16 (278) Ch 8 (5)
Pink Ch 15 (277) Ch 7 (6)
Gray Ch 14 (276) Ch 6 (7)
Blue Ch 13 (275) Ch 5 (8)
Yellow Ch 12 (274) Ch 4 (9)
Orange Ch 11 (273) Ch 3 (10)
Purple Ch 10 (272) Ch 2 (11)
Brown Ch 9 (271) Ch 1 (12)
* Note that the pin numbers for A and B are out of order
