1126800 SmartPAC 2 with WPC Integration
Page 110 Chapter 2 Installing SmartPAC 2 and WPC
Determine Top Stop Angle If Press Stopped BEFORE TDC (Between 181°
°°
° and 360°
°°
° )
If the press stopped BEFORE TDC, follow the steps below. Refer to the example given.
1.
In Step 2 on the previous page find the Average value for the Angle the Press Stopped.
Write it in the box below. You will use this as “Angle the Press Stopped”
°
Angle the Press Stopped
2. Select PRESS CONTROL from the Run menu. Read the Top Stop Angle on the screen
that appears. The Top Stop Angle is the number of degrees it took the press to stop after
the Top Stop cam turned on. Write the Top Stop Angle in the box below. Use this as the
“Old Top Stop Angle” in the steps below.
°
Old Top Stop Angle
Go to the next page.
