SmartPAC 2 with WPC Integration 1126800
Installing SmartPAC 2 and WPC Chapter 2 page 119
Top Stop Angle between 241°
°°
° and 270°
°°
° : Install Overrun Sensor Magnet
1. Go to Initialization mode (page 203). Select PRESS CONTROL. Select PRESS
OPTIONS. On the screen that appears, set Switches 1 and 2 as follows:
Switch 1 – CLOSED
Switch 2 – OPEN
To change a switch setting, highlight it and press ENTER to toggle between OPEN and
CLOSED. Press RESET when done.
2. Power down SmartPAC 2 with WPC and power it up again. This makes the new switch
settings take effect.
3. Go to Run mode and turn the Stroke Select key to OFF and then back to Inch to clear the
LOCKOUT message (see page 387).
4. Go to Initialization mode. Select RESOLVER ZERO. On the screen that appears, find
“Current Zero Correction.” Write the Current Zero Correction here: _ ° .
5. Go to Table 2 - 13. Find the Current Zero Correction value in the appropriate column in
the table. Circle the “Crankshaft Angle” next to it.
Table 2 - 13. Top Stop Angle bet. 241°
°°
° and 270°
°°
° : Mounting Overrun Magnet
(Unzeroed Resolver Angle = 300° )
Zero Correction 0°
°°
° - 30°
°°
° Zero Correction 330°
°°
° - 359°
°°
°
Current
Zero
Correction
Crankshaft
Angle on
Display
Current
Zero
Correction
Crankshaft
Angle on
Display
Current
Zero
Correction
Crankshaft
Angle on
Display
Current
Zero
Correction
Crankshaft
Angle on
Display
0
300
15
285
330
330
345
315
1
299
16
284
331
329
346
314
2
298
17
283
332
328
347
313
3
297
18
282
333
327
348
312
4
296
19
281
334
326
349
311
5
295
20
280
335
325
350
310
6
294
21
279
336
324
351
309
7
293
22
278
337
323
352
308
8
292
23
277
338
322
353
307
9
291
24
276
339
321
354
306
10
290
25
275
340
320
355
305
11
289
26
274
341
319
356
304
12
288
27
273
342
318
357
303
13
287
28
272
343
317
358
302
14
286
29
271
344
316
359
301
30
270
6. Go to Run mode. Turn the Stroke Select key to “Inch.” Inch the press until the
SmartPAC 2 display shows the Crankshaft Angle you circled in Table 2 - 13.
