TAP-112: Trouble Clearing 365-575-102
Page2of4 Issue8.0,July2002
3. Is the indicated slot empty?
If YES, then continue with Step 4.
If NO, then go to TAP-108.
4. Do the office records show that the slot should contain a circuit pack?
If YES, then continue with Step 8.
If NO, then continue with Step 5.
5. At the CIT, select CONFIGURATION-Update (records the current hardware
arrangement in SYSMEM circuit pack).
6. Replace the shelf cover.
Reference: DLP-511
7. STOP! YOU HAVE COMPLETED THIS PROCEDURE.
8. Obtain the missing circuit pack and install it into the appropriate slot. As
required, make the appropriate optical connections on the OC3, RCVR,
TRMTR, or REGENR circuit pack(s).
Reference: DLP-514
9. Wait for the time indicated in Table B:
* Inserting an LNCTL circuit pack starts a mini reset that can take up to 10 minutes to complete. During this
time, LEDs on other circuit packs will be lighted.
† When a TG3 circuit pack is first inserted, it will be switched out of service until it warms up. This can take as
long as 5 minutes. You can confirm that it is in the standby state by using the FAULT-Retrieve-State
command for the TG slot.
10. Is the FAULT LED lighted on the replacement circuit pack?
If YES, then replace shelf cover and go to Trouble Clearing: IXL-001.
If NO, then continue with Step 11.
Table B - Mini Reset Waiting Times
CP Inserted Waiting Time
LNCTL * 10 minutes
OHCTL 5 minutes
TG3 † 5 minutes
TOHCTL 5 minutes
All Others 1 minute
To Next Page
