365-575-102 TroubleClearing:
Issue 8.0, July 2002 Page 1 of 4
TAP-112
Clear ‘Circuit Pack Removed’
Overview: This procedure is used to clear one of the conditions below by (1)
installing the missing circuit pack or (2) updating the SYSMEM circuit pack to reflect
the current equipage:
DS3 INTFC removed REGENR removed
LNCTL removed STS1E INTFC removed
LSSW removed TG3 removed
OC3 INTFC removed TOHCTL removed
OC12 INTFC removed OHCTL removed
TRMTR removed RCVR removed.
1. Identify the appropriate shelf associated with the removed circuit pack, using
Table A:
2. Remove the appropriate shelf cover.
Reference: DLP-511
Table A - Shelf and Associated Circuit Packs
Removed Circuit Pack Shelf
DS3
LSSW Low Speed Shelf - Complementary
OC3 or
STS1E Low Speed Shelf - System Controller
OC12
TG3
TOHCTL
LNCTL High Speed Shelf
OHCTL or
RCVR Enhanced High Speed Shelf
TRMTR
REGENR Repeater Bay/Shelf
