365-575-102 Detailed Level Procedure: DLP-501
Issue 8.0, July 2002 Page 1 of 2
Connect and Condition Craft Interface Terminal (CIT)
Overview: This procedure provides instructions to verify the CIT [a personal
computer (PC) running FT-2000 CIT-PC software] is properly connected, powered,
and has software installed. If you are unfamiliar with the PC, an "Introduction to the
PC" is provided in DLP-529.
NOTE:
The PC must meet the minimum requirements as stated in the "Craft
Interface Terminal" part of Section 6, "Operations Interfaces."
1. Verify the PC is safely positioned on the PC tray (bay shelf) or safely secured
on a cart or table.
2. Verify the cable connections at the PC.
Reference: 365-575-104,
FT-2000 OC-48 Lightwave System, Releases 1
and 2, Installation Manual
, and 365-575-115,
FT-2000 OC-48 Lightwave
System, Releases 3, 4, 5, 6, and 7, Installation Manual
. To summarize,
check the following:
• The appropriate 9-pin or 25-pin cable or equivalent interface cable is con-
nected between the CIT (DCE) female connector on the user panel and a
serial male connector on the PC.
• If required, a printer with the appropriate printer cable is connected to the
CIT per the instructions provided with the printer.
• If required, a modem (internal or external) is connected per the instruc-
tions provided with the modem. Many modem configurations exist and
operate over the public switched network or a data communications net-
work (
Datakit
u
â
d network).
Reference: DLP-521 (Establish modem or
Datakit
network access.)
3. Turn the PC power switch to "on."
4. Verify the PC prompt is displayed (typically C:>).
Reference: DLP-529
5. Is the FT-2000 CIT-PC software loaded on the PC?
If YES, then continue with Step 9.
If NO, then go to Operation: NTP-002.
If DON'T KNOW, then continue with Step 6.
To Next Page
