DLP-503: Detailed Level Procedure 365-575-102
Page 6 of 10 Issue 8.0, July 2002
Protection Access Upgrade
!
CAUTION:
Care must be used at the cross-connect bay because traffic is being
carried on the DSs from the low speed shelf - system controller. At this
time, traffic is not on the protection access shelf.
14. At the low-speed cross-connect bay (that is, DSX-3, STSX-1, DACS III-2000,
etc.), loop back only the low-speed circuits that are associated with protection
access. Do not use the FAULT-Operate-Loopback command at the
FT-2000 network element. Loopback is toward the FT-2000 network element.
15. Is the NE ACTY LED lighted?
If YES, then refer to Trouble Clearing: IXL-001.
If NO, then continue with Step 16.
16. At the CIT, select FAULT-Test-Auto Turnup (use CONFIGURATION in
Release 1.1.1) with Mode: DSX and P fortheline.Thistestcantakeupto5
minutes.
Response: The ABN and NE ACTY LEDs are lighted.
NOTE:
A"g" is for good or successful test. A "-" is for not tested. An "F" is for failed or
unsuccessful test.
17. Does report indicate "g" for good or "-" for not tested for each entry?
(See Figure 4 for protection line only in a point-to-point network.)
If YES, then continue with Step 18.
If NO, then refer problem to the group that installed the equipment.
18. Remove cross-connect loopback(s) established in Step 14.
19. At the CIT, select CONFIGURATION-Update.
20. STOP! YOU HAVE COMPLETED THIS PROCEDURE.
