365-575-102 DetailedLevelProcedure:
Issue 8.0, July 2002 Page 1 of 2
DLP-504
Perform Provisioning
Test Office Alarm Operation
1. At the CIT, select FAULT-Test-Alarm and Mode: All with Repeat: 1.
2. Verify the CR, MJ, and MN visual LEDs are sequentially
lighted
for 4 seconds
and then remain
off
per the sequence chart below. Also, the office audible
alarms should be activated during this test.
3. Did the office alarms operate as described?
If YES, then STOP! YOU HAVE COMPLETED THIS PROCEDURE.
If NO, then refer problem to the group that installed the equipment.
Step* Alarm LEDs at User Panel
CR MJ MN
1 off off off
2 on off off
3 off on off
4 off off on
5 off off off
* Each step has a 4-second duration.
To Next Page
