365-575-102 DetailedLevelProcedure:
Issue 8.0, July 2002 Page 1 of 2
DLP-509
Test Serial Telemetry
Overview: This procedure is used to test the serial telemetry points. These points
transfer alarm, status, and control information to a remote operations center. The
transfer via a modem link uses a telemetry byte-oriented serial (TBOS) protocol to a
remote maintenance or operations center. This procedure is performed during the
acceptance of the FT-2000 network elements when they are out of service and is
performed only during this time. For additional information, refer to "Serial Telemetry
Interfaces" part in Section 6, "Operations Interfaces."
1. Contact the remote operations center and request their assistance in
monitoring the serial telemetry points during this test.
2. At the remote operations center, disable the alarm threshold level for the
telemetry points being tested.
3. At the local CIT, select FAULT-TEST-TELEMETRY-SERIAL, SERIAL
TELEMETRY LINK: 1, DISPLAY: 1, POINT: even, odd, or all, and
Repeat: 1 through 10.
Response: Up to 64 serial telemetry points are activated for 20 seconds
for the specified display and the specified link before reverting to normal
operation.
Table A - Serial Telemetry Points
Display Shows Alarm, Status, and Control Points
1 For local service line
2 For local protection line
3 For remote service line
4 For remote protection line
5 Reserved for future use
6 Reserved for future use
7 Reserved for future use
8 Reserved for future use
