DLP-512: Detailed Level Procedure 365-575-102
Page 2 of 14 Issue 8.0, July 2002
1.
!
WARNING:
Unterminated optical connectors may emit invisible laser radiation. Eye damage
may occur if beam is viewed directly or with improper optical instruments. Avoid
direct exposure to beam.
!
CAUTION:
Use a static ground wrist strap whenever handling circuit packs or working on an
FT-2000 network element to prevent electrostatic discharge damage to sensitive
components.
1. Is the buildout being installed or removed (see Figure 1)?
If Installed on a High Speed fiber, then continue with Step 2.
If Installed on a Low Speed fiber, then continue with Step 16.
If Removed, then continue with Step 35.
High Speed Fiber Installation via an LGX
2. While considering the application (Table A), and as appropriate, select the cor-
rect jumper from Table B.
NOTE:
When connecting to an LGX, you will need one jumper for the transmit fiber
and an identical jumper for the receive fiber.
3. Install/connect the selected jumpers at the LGX.
Table B – Single-mode Lightwave Jumpers for Low-Speed and
High-Speed Fiber Connection
Code Comcode Length Description
FS1E-E-02 105 357 727 2 ft. ST-ST
FS1E-E-10 105 357 768 10 ft. ST-ST
FS1E-E-25 105 357 800 25 ft. ST-ST
FS1E-E-50 105 357 859 50 ft. ST-ST
FS1E-E-100 105 357 875 100 ft. ST-ST
LS1K-E-10 105 713 150 10 ft. Biconic-ST
LS1K-E-25 105 712 939 25 ft. Biconic-ST
LS1K-E-50 105 712 988 50 ft. Biconic-ST
LS1K-E-100 105 712 947 100 ft. Biconic-ST
LS1FP-FP 106 470 446 As Req'd. FC/PC-FC/PC
To Next Page
