Lucent Technologies FT-2000 OC-48 - Page 1416

DLP-521: Detailed Level Procedure 365-575-102
Page 2 of 10 Issue 8.0, July 2002
Figure 1 – CIT/FT-2000 Network Element Configurations
CIT-PC
Modem
Figure 1 - External Modem Configuration
External
Modem
Public Switched
Network
DTE
Port
CIT-PC
Modem
Figure 2 - Internal Modem Configuration
Public Switched
Network
DTE
Port
Internal
Modem
CIT-PC
DTE
Port
Datakit
Network
Node
Datakit
Network
Node
Figure 3 - Network Configuration Datakit
CIT-PC
DTE
Port
Datakit
Network
Node
Internal
Modem
Modem
Public Switched
Network
Modem
Figure 4 - Hybrid Network Configuration
