DLP-521: Detailed Level Procedure 365-575-102
Page 8 of 10 Issue 8.0, July 2002
40. After completing your work, log out of the FT-2000 network element by
pressing function key F4, labeled LOGOUT, or exit the software by pressing
function key F5, labeled EXIT. At this time, you may press F3 again to
establish a new connection to a different FT-2000 network element.
41. STOP. YOU HAVE COMPLETED THIS PROCEDURE.
Table A. Pin Connections at CIT (DTE) Connector
CIT (DTE) Connector (Note) FT-2000 Network Element
Pin 1 - Protective Ground Protective frame ground.
Pin 2 - Transmit Data Transmits data to the modem.
Pin 3 - Receive Data Receives data from the modem.
Pin 4 - Request to Send FT-2000 network element notifies the
modem that it is ready to send data.
Pin 5 - Clear to Send Modem notifies the FT-2000 network
element that it is clear to send its data
Pin 6 - Data Set Ready Modem notifies the FT-2000 network
element that the modem is connected and
ready to receive data.
Pin 7 - Signal Ground Signal ground.
Pin 8 - Receive Line Signal
Detected
This modem has detected carrier from the
remote modem.
Pin 20 - Data Terminal Ready FT-2000 network element notifies the
modem that it is connected.
Note: All remaining pins are not connected.
