DLP-526: Detailed Level Procedure 365-575-102
Page2of4 Issue8.0,July2002
9. Remove the dirty air filter located right above the PC tray by sliding it toward
you.
10. Install the replacement filter by sliding it into the bay within the filter guides,
with the arrows on the filter pointing up.
NOTE:
Air flow in the bay is from bottom to top (up).
11. Dispose of the dirty air filter per the local operating instructions.
12. After the filter replacement has been completed, close the screen and rotate
the 1/4-turn fasteners 90 degrees clockwise until each screw slot is horizontal.
13. Insert the two FAN power plugs into their respective connectors ("A" plug has
red/black wires and "B" plug has slate with black strip/slate wires). The two
FAN power plugs are keyed and when connected properly, the "A" plug has a
red wire on the left and the "B" plug has a slate wire with a black strip on the
left.
Response: The POWER ON LED at the fan assembly is lighted.
14. Reposition the front cover of the Power Distribution and Fuse Panel and
secure it using the two screws.
15. STOP! YOU HAVE COMPLETED THIS PROCEDURE.
