Platform Descriptions
3-28 Issue 8.0 July 2002
Circuit pack keying prevents circuit packs from being accidentally inserted in
incorrect slots.
For detailed circuit pack descriptions and software compatibility information, refer
to Section 7, "Circuit Pack Descriptions."
Enhanced High-Speed Shelf Interfaces 3
Front access cabling is provided through the interconnection panel (Figure 3-15).
Figure 3-15. Interconnection Panel (Enhanced High-Speed
Shelf)
LINE OW
(EXP OW)
J276A
LINE (X)
LINE (Y)
J256A
LINE (Y)
LINE
NO. X = 1W
LINE
NO.Y = 1E
J257A
J277A
LINE (X)
LINE (Y)
INTRAOFFICE
LAN
SECTION
USER CHAN
J272A
LINE (X)
LINE (Y)
J254A
LINE (X)
SECTION OW
(LOC OW)
J274A
J252A
LINE GROWTH
CHAN
J251A
J271A
LINE (X)
LINE (Y)
nc-ft2000-040
