DLP-537: Detailed Level Procedure 365-575-102
Page4of4 Issue8.0,July2002
Figure 1 – Example of STS-1 Cross-Connections (Using External Cables)
1
2
3
2B
1
2
3
4A
STS-1 Granularity
Shows 2-Way Time
Slot Assignments
External
Cables
1W
1E
tpa 832887/01
DSX-3 and/or STSX-1
Cross-Connect Panel
FT-2000 OC-48 Add//Drop-Rings Terminal
