Platform Descriptions
Issue 8.0 July 2002
3-31
Heat Baffle 3
The heat baffles prevent heat rising from the shelf below from entering the shelf
above. A front cover is provided to maintain a flush appearance.
PC Tray 3
The PC tray is a combination PC tray and heat baffle. It provides a place to hold a
portable PC (for example, the
NCR*
3170 computer) weighing up to 25 pounds
and measuring up to 20 inches wide and 12 inches deep. It can also serve as a
writing tray. This fixture folds into the heat baffle when not in use. A front cover is
also provided to maintain a flush appearance.
*
Screen 3
The screen provides a filter panel at the bottom of the bay and an air intake
plenum for cooling purposes.
* Trademark of NCR Corporation.
