365-575-102 Detailed Level Procedure: DLP-550
Issue 8.0, July 2002 Page 5 of 16
6. Notice that this exposes the four screws on the corners of the User Panel, sim-
ilar to one of the panels depicted in the following figure.
7.
!
CAUTION:
DO NOT ALLOW the screws to fall into the bay.
Remove the four corner screws from the User Panel.
8. Set the User Panel aside, being careful not to short out any of the electrical
connections on the back of the panel.
USE
CIT
CIT
(DCE)
W
LINE
LOCTR
NE
ACTY
FE
ACTY
MN
ABN
ACO/
LOCTR
ESD WRIST
STRAP GROUND
PWR
ON
MJ
E
CR
nc-ft2000-028
ESD WRIST
STRAP GROUND
PWR
ON
LINE
NO. = 1W
LINE
NO. = 1E
LINE
NO. = 1W
LINE
NO. = 1E
