365-575-102 Detailed Level Procedure: DLP-550
Issue 8.0, July 2002 Page 15 of 16
Figure 6 – Power Connections for Power Line Filter Module
Set Scre
w
Thick Black Lead to
-48vr
nc-ft2000-023
Feeder A Connections
Thin Black
Lead to Fl
Red Lead to -48v
Set Scre
w
Grey With Black Stripe
-48vr
nc-ft2000-024
Feeder B Connections
Thin Black
Lead to Fl
Grey Lead to -48v
